UB2000-30GM-E5-V15

UB2000-30GM-H3

ultrasonic sensor

Single head system

List of Main Advantages

Individual evaluation

Direct detection mode

General Specifications

detection range80 . .. 2000 mm

adjustment range120 . .. 2000 mm

dead zone0 . .. 80 mm 1)

Standard target board100 mm x 100 mm

Transducer frequencyApproximately 180 kHz

Electrical Technical Specifications

Working VoltageUB10 . .. 30 V DC ， Ripple 10% SS

no-load currentI0≤ 30 mA

input

input type1-channel pulse input (clock) for transmitter pulses

0 level (active):<5 V (UB>15 V)

1 level (inactive):>10 V...+UB (UB>15 V)

0 level (active):<1/3 UB (10 V<UB<15 V)

1 level (inactive):>2/3 UB...+UB (10 V<UB<15 V)

Pulse length20 . . 300 µ s (typical value 200 µ s) 2)

Pulse length≥ 50 x pulse length

impedance10 kOhm internal connection to+UB

output

output type1-channel pulse output, corresponding to echo transmission time, short circuit protection

Open collector PNP with pull-down resistor=22 kOhm

Level 0 (no echo): - UB

Level 1 (detected echo): ≥ (+UB-2 V)

Rated working currentIe15 mA ， Short circuit/overload protection

temperature effectEcho transmission time: 0.17%/K

environmental conditions

ambient temperature-25 . .. 85 °C (-13 ... 185 °F)

Storage temperature-40 . .. 85 °C (-40 ... 185 °F)

Mechanical Specifications

Protection levelIP67

connect2 m PVC cable 0.75 mm2

material

shellNickel plating on brass; Plastic components: PBT

transducerEpoxy resin/hollow glass sphere mixture; polyurethane foam

quality300 g

size

length80 mm

diameter30 mm
