Integrated filter power module TRI10-1211 TRI10-1212

Integrated filter power moduleTRI10-1211 TRI10-1212 TRI10-1213 TRI10-1215

TRI 10It is a high insulation power supply with stable voltage10tileDC / DCConverter series, using compactDIP-24Encapsulation.TRI 10The core feature of the series is a complex enhanced insulation system that can withstand high test voltages（1sfor9000 VDC，60sfor5000 VAC）And working voltage（1000 VACrms）. As a supplement to this insulation characteristic, there is also15 kV / µsHigh common mode transient immunity. The new design of this power supply sold by Haonan Electronics allows for the integration of filters and greatly reduces no-load power consumption.88%The efficiency allows for40°Cto+ 65°COperate within the temperature range without the need for derating, and can operate during derating+ 85°CAll models have2：1Wide input voltage range and accurately regulated insulation output voltage.TRI 10The series is a good choice for many demanding applications in the industrial, transportation, and instrumentation industries.

feature

EnhancedI / Oinsulation5000 VACThe rated working voltage is1000 VAC

Peak insulation voltage9000 VDC（1s）

Common mode transient immunity（dv / dt）15 kV / µs

Working temperature range-40to+ 85°C

Low no-load power consumption144 –288 mW

Internal filter

efficiency88％

2：1Input voltage range:9-18、18-36The36-75 VDC

Overload, overvoltage, and short circuit protection

3Annual product warranty

Integrated filter power module TRI10-1211 TRI10-1212

Provided for industrial useAC/DCPower module, output power is5－100W,The open output power is10－500WIn addition, there are metal encapsulated modules with an output power of15－1000W.

laminatedEncapsulated AC/DC 5～100W

open-endedOpen Frame AC/DC 10～500W

Metal sealEncase AC/DC 15～1000W

DIN-Rail Power Supplies（TRACO POWERRail power module)TRACO POWERWe are a manufacturer of industrial guide rail (track) modules with a wide range of product applications600WGet itATEXof

DIN-Rail Power Supplies：15－600W

DC / AC Inverters ( TRACO POWER DC/ACinverter)

InTESIn the series, we offer a range of training inverters. The output frequency is50/60or400HZInput voltage from24VDCto600VDC.

The original factory provides a three-year warranty for the product;
