HDYAC Hedeke hydraulic control valve RVM06020-51-C-N-0.5
NegotiableUpdate on 02/11
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
HDYAC Hedeke hydraulic control valve RVM06020-51-C-N-0.5 $r $n model analysis: $r $nRVM06020: series identification, may represent diameter or flow specification $r $n01: valve body size or functional variant code $r $nC: valve core type $r $nN: standard installation method $r $n0.5: set pressure or flow parameter $r $n Performance parameter $r $n Working pressure: not clearly marked, but the same series of hydraulic control check valves (such as RVM06020-51-C-N-5.0) support high-pressure working conditions $r $n Applicable media: hydraulic oil, lubricating oil and other industrial fluids $r $n Connection method: plug-in (requires valve block coordination) Installation)
Product Details
HDYAC Hedeke hydraulic control valve RVM06020-51-C-N-0.5
modelCone lift valve type
functioncheck valve
adjustment typeUnavailable
cavity06020
Valve Qmax [l/min]38
Product SeriesRVM06020
Open pressure [bar]0.5
Volume flow range Q [l/min]0 - 38
nominal size6
object nameRVM06020-51-C-N-0.5
Pmax [bar]350
control type直接作用式
Installation Typemetric system
sealing materialNBR
Part Number3347965
RVM06020-51
38 liters per minute
350 bar
Check valve RVM06020-51 is
Direct acting spring-loaded lift valve
valve
When there is no water flow passing through
The valve and spring fix the lift valve in place
Close position, therefore close
From port 1 to port 2. The valve is open.
When the pressure at port 1 is high
The pressure of Port 2, including
The pressure generated by the spring force.
feature
High performance version with high cycle rate
The main application is to prevent uncontrolled movement or crawling of loads
The closed part of the cylinder and system
Galvanized outer surface
Hardening and grinding of valve components to ensure minimal wear and elongation
service life
Optimizing the flow channel through CFD to achieve low pressure drop
Improved wear resistance through guiding and damping pistons
Specifications
Work pressure: 350 bar
Installation: No directional restrictions
Material: Valve body: High strength steel
Pistons: Hardened and ground steel
Sealing element: NBR (standard)
FKM (optional, media)
Temperature range -20 ° C to+120 ° C
Support ring: PTFE
Chamber: Metric 06020
Weight: 0.07 kilograms
Nominal flow rate: 38 liters per minute
Internal leakage: 0.064 cubic centimeters at 350 bar
Burst pressure: 0.5 bar (other pressures provided upon request)
Medium operating temperature range: Low -30 ° C to High+100 ° C
Environmental temperature range: Low -30 ° C to High+100 ° C
Working fluid: Hydraulic oil in accordance with DIN 51524 Part 1 and Part 2
Viscosity range: minimum 10 mm ²/s to maximum 420 mm ²/s
Filtering: According to ISO 4406 levels 21/19/16 or
cleaner
MTTFd: 150 years (see "Conditions and
Valve Instructions in Manual 5.300
HDYAC Hedeke hydraulic control valve RVM06020-51-C-N-0.5
