- Cantilever beam impact testing machine
- Rapid temperature and humidity change test chamber
- Large high and low temperature test chamber
- Composite salt spray corrosion test chamber
- Condensed water test chamber
- High Temperature Test Chamber
- Temperature and humidity bending testing machine
- High and low temperature damp heat test chamber
- Step in constant temperature and humidity test chamber
Dongguan Haotian Testing Equipment Co., Ltd
Composite salt spray cyclic corrosion test chamber salt spray drying and wetting test
NegotiableUpdate on 02/11
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Compound salt spray cyclic corrosion test box Salt spray drying and wetting test Main functions of the test box Acetic acid salt spray test (ASS), copper salt accelerated acetic acid salt spray test (CASS), drying test, temperature and humidity test Salt spray precipitation amount: Salt spray settling amount: (1-5) ml/80cm2/h (adjustable) Suitable for: metals and their alloys, metal coatings (anodic and cathodic), conversion coatings, anodization coatings, organic coatings on metal materials, etc
Product Details
Composite salt spray cyclic corrosion test chamber salt spray drying and wetting test
function
Large salt spray test chamber with built-in functions:
Salt spray, drying, wetting, soaking, constant temperature and humidity tests, etc.
Test conditions
Complies with the salt dry wet composite test method: salt spray test → hot air forced drying test → moisture test
(A) Salt water spray test: NSS, ACSS, CASS, SWAAT
Laboratory temperature: Salt water test method (NSS ACSS) 35 ± 0.1 ℃ Corrosion resistance test method (CASS) 50 ± 1 ℃, salt 5% water 95% ratio
Saturated air tank temperature: Salt water test method (NSS ACSS) 47 ± 0.1 ℃ Corrosion resistance test method (CASS) 63 ± 1 ℃
Spray volume: 1.0~2.0ml/80c ㎡/h (collect at least 16 hours and take the average value)
PH value: Saltwater test method (NSS ACSS 6.5-7.2) Corrosion resistance test method (CASS) 3.0~3.2
(B) Hot air drying test (DRY):
(1) Temperature: 60 ℃± 2 ℃
(2) Humidity: RH ≤ 30%
(C) Humidity test (SOAK):
(1) Temperature: 23 ℃± 2 ℃, humidity: 50% ± 5%
(2) Temperature: 40 ℃± 2 ℃, humidity: RH ≥ 98%
(3) Humidity: 50 ℃± 2 ℃, humidity: RH ≥ 98%
Composite salt spray cyclic corrosion test chamber salt spray drying and wetting test
Accessibility
It can display the current execution program number, segment number, remaining time, and number of cycles, with real-time display of curve execution function Switching between Chinese and English, display of fault prompt screen, and adjustable backlight on the screen
Equipped with power-off program memory, it automatically starts and continues to execute program functions after power restoration. Equipped with RS-232 communication interface and USB data download function.
It has the function of automatic adjustment of freezing capacity, and has the function of scheduled start-up and shutdown.
It has date and time adjustment functions, button and screen lock (LOCK) functions.
Technical Specifications:
Temperature range: Rt+10 ℃~60 ℃± 1 ℃
Humidity range: 30% -98%<can be adjusted according to customer's actual requirements>R.H only displays measured values
Temperature fluctuation: ± 1 ℃
Temperature deviation: ± 1.0 ℃
Salt spray settling rate: 1.0~2.0Ml/80cm2/h (collect for at least 16 hours and take the average)
Working hours: continuous/intermittent
Salt solution settling direction: free settling
Air intake system: The machine itself does not have an air supply system, and is supplied by an external air compressor
Spray method: A. Airflow spray method, continuous and intermittent. The spraying of salt spray is provided through compressed air pipelines. B. Gas saturation purifier: heats, removes oil, and humidifies gas to become a saturated gas that is isothermal, clean, and humid with the box.
